快恢復整流器

結果：82
已用篩選：整流器件 > 快恢復整流器
IO(A)
0.2
0.5
1
2
3
6
8
10
12
16
20
30
VRM(V)
50
100
200
400
600
800
1000
1200
1400
1600
1800
2000
2500
3000
4000
5000
IFSM(A)
30
50
80
100
125
200
250
IR(mA)
5
10
VF(V)
1.6
1.5
1.3
2.5
4
5
6.5
7
TRR(nS)
35
150
250
500
@Tj (℃)
75
150
PACKAGE
SMA
TO-220AC
DO-41
DO-15
R-6
A-405
TO-247
DO-201AD
R-1
TO-220AB
DO-41/DO-15
ITO-220AC
PART-NO IO(A) VRM(V) IFSM(A) IR(mA) VF(V) TRR(nS) @Tj (℃) PACKAGE DOWNLOAD
1F1 1 50 30 5 1.3 150 150 R-1
1F2 1 100 30 5 1.3 150 150 R-1
1F3 1 200 30 5 1.3 150 150 R-1
1F4 1 400 30 5 1.3 150 150 R-1
1F5 1 600 30 5 1.3 250 150 R-1
1F6 1 800 30 5 1.3 500 150 R-1
1F7 1 1000 30 5 1.3 500 150 R-1
FR101S 1 50 30 5 1.3 150 150 A-405
FR102S 1 100 30 5 1.3 150 150 A-405
FR103S 1 200 30 5 1.3 150 150 A-405
FR104S 1 400 30 5 1.3 150 150 A-405
FR105S 1 600 30 5 1.3 250 150 A-405
FR106S 1 800 30 5 1.3 500 150 A-405
FR107S 1 1000 30 5 1.3 500 150 A-405
FR101 1 50 30 5 1.3 150 150 DO-41
FR102 1 100 30 5 1.3 150 150 DO-41
FR103 1 200 30 5 1.3 150 150 DO-41
FR104 1 400 30 5 1.3 150 150 DO-41
FR105 1 600 30 5 1.3 250 150 DO-41
FR106 1 800 30 5 1.3 500 75 DO-41
